BX series
LEABON
New Type Mobile Electric Diesel Engine Tree Shredder Disc Type Wood Chipper for Sale
Introduction:
The machine can chip wood branches into settled dimensions, for producing fiberboard, pulp etc. Can be made as up outlet or down outlet according to users’ requirement, also can be driven by diesel engine, for using in somewhere no electricity.
1. Specially designed for round logs, square blocks, and wood staff into 10-30mm size small wood pieces
3. Final chipps like these
3. Contains feeding belt conveyor and electrical cabinet. Easy operation, simple maintenance, low noise and highly working efficiency
4. Best choices for dealing with wood scraps
Spare parts:
Blades
Detail photos
New Type Mobile Electric Diesel Engine Tree Shredder Disc Type Wood Chipper for Sale
Introduction:
The machine can chip wood branches into settled dimensions, for producing fiberboard, pulp etc. Can be made as up outlet or down outlet according to users’ requirement, also can be driven by diesel engine, for using in somewhere no electricity.
1. Specially designed for round logs, square blocks, and wood staff into 10-30mm size small wood pieces
3. Final chipps like these
3. Contains feeding belt conveyor and electrical cabinet. Easy operation, simple maintenance, low noise and highly working efficiency
4. Best choices for dealing with wood scraps
Spare parts:
Blades
Detail photos
Technical data:
Item | BX-600 | BX-800 | BX-950 | BX-1200 | BX-1400 | BX-1600 |
Knife disk diameter (mm) | 600 | 800 | 950 | 1200 | 1400 | 1600 |
Knife quantity(pcs) | 3 | 4 | 6 | 6 | 6 | 6 |
Input opener(mm) | 150*140 | 170*160 | 220*210 | 350*250 | 460*350 | 540*380 |
Max Input diameter(mm) | 130 | 150 | 200 | 250 | 300 | 350 |
Capacity (m3/h) | 1-3 | 3-6 | 8-12 | 12-18 | 20-30 | 30-45 |
Main motor (kw) | 22KW | 37KW | 55KW | 90kw | 110 | 160 |
Dimension(m) | 1.6*1*1.4 | 1.8*1.1*1.5 | 2*1.2*1.6 | 2.8*1.5*1.63 | 3.5*1.78*1.8 | 3.8*1.85*2.1 |
Weight (kg) | 880 | 1680 | 2180 | 3580 | 4950 | 8750 |
Final chips’ length (mm) | 20-35 | 20-35 | 25-35 | 25-40 | 25-40 | 25-40 |
Advantage:
1. CE approved, quality guarantee
2. High capacity and low investment
3. Structure reasonable and Firm durable
4. Safe reliable and Easy operation
Usage:
Wood chipper machine can cut wood, branches, bamboo into small pieces, which is extensively applied in the material-preparing of pulp paper-making, OSB and MDF production and also in the individual wood chips production, different capacity we can supply, please contact for more news.
Wood chipper in production - belt conveyor
Wood chipper in production - wood chips storage bin:
Final wood chips of different size:
Technical data:
Item | BX-600 | BX-800 | BX-950 | BX-1200 | BX-1400 | BX-1600 |
Knife disk diameter (mm) | 600 | 800 | 950 | 1200 | 1400 | 1600 |
Knife quantity(pcs) | 3 | 4 | 6 | 6 | 6 | 6 |
Input opener(mm) | 150*140 | 170*160 | 220*210 | 350*250 | 460*350 | 540*380 |
Max Input diameter(mm) | 130 | 150 | 200 | 250 | 300 | 350 |
Capacity (m3/h) | 1-3 | 3-6 | 8-12 | 12-18 | 20-30 | 30-45 |
Main motor (kw) | 22KW | 37KW | 55KW | 90kw | 110 | 160 |
Dimension(m) | 1.6*1*1.4 | 1.8*1.1*1.5 | 2*1.2*1.6 | 2.8*1.5*1.63 | 3.5*1.78*1.8 | 3.8*1.85*2.1 |
Weight (kg) | 880 | 1680 | 2180 | 3580 | 4950 | 8750 |
Final chips’ length (mm) | 20-35 | 20-35 | 25-35 | 25-40 | 25-40 | 25-40 |
Advantage:
1. CE approved, quality guarantee
2. High capacity and low investment
3. Structure reasonable and Firm durable
4. Safe reliable and Easy operation
Usage:
Wood chipper machine can cut wood, branches, bamboo into small pieces, which is extensively applied in the material-preparing of pulp paper-making, OSB and MDF production and also in the individual wood chips production, different capacity we can supply, please contact for more news.
Wood chipper in production - belt conveyor
Wood chipper in production - wood chips storage bin:
Final wood chips of different size:
