LB-SS1100
LEABON
Fully Automatic Buckle Free Goods Steel Belt Threading And Bundling Machine Price
Features for this steel strip packing machine
PLC control
Steel strip belts are suitable.
Striping in the "#" font
Can be used in automated packaging production lines to save labor.
Technical data for this steel strip packing machine
Model | Packing speed (without piercing arrows) | Packing material | Effective binding size (L*W*H) |
LB-SS1100 | 25 S/piece, (the bundling head moves up and down) | Wood board | 1100*1100*900 |
Packing material weight | Use packing tape | Steel strip size | Number of straps |
Max. 3500kg | steel strip | width 32 ± 0.5 mm; thickness 0.8~0.9 mm | 2 * 2 "#" shaped packaging) |
Equipment workbench height | Connection method | Connection position | Belt tightening force |
750 ± 30 mm (to be determined) | Buckle free | 12 o'clock position on the top surface | 1500-20000 N |
Environmental temperature | Environmental humidity | Operating noise | Connection tension |
-5~50 ℃ | <99% | <85 decibels | 80% of the bonding strength |
Electrical control | Overall power | Voltage | corner protection device and steering table can select |
PLC (Siemens S7-12xx) | 5kw | 380V |
Items for this steel strip packing machine
Item | fully automatic baling machine | Baling Head and Protective Mechanism | Steel main frame | Up and down movement mechanism | Conveyor groove | Automatic angle protection mechanism (Optional) | Disc (including belt storage and brake) ABK | Electric control cabinet (Siemens PLC) | Testing the Baling Strap |
QTY | 1 | 2 | 1 | 1 | 2 | 2 | 2 | 1 | 2 |
Main part for this steel strip packing machine
Strapping head--------- Using steel strip bundling head
Drive | Feeding speed | Combination method | Tensile force | Can use bundling straps | Picture |
Electric motor |
| Buckle free connection | Max. 20000N (adjustable) | steel straps with a width of 32mm and a thickness of 0.8-0.9mm |
|
Banding method for this steel strip packing machine
Binding method for this steel strip packing machine
More pictures for this steel strip packing machine
