CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
You are here: Home » Products » Wood Pellet Machine » Ring-die wood pellet machine » CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale

loading

CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale

CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale

Availability:
Quantity:
  • LH-350 LH-420 LH-678

  • LEABON

  • 8479820090

CE Certified European Popular Horizontal Ring Die-Cutting Wood Pellet Machine for Sale
Product Description

CE certified European popular horizontal ring die-cutting wood pellet machine for sale


 Specification of wood pellet machine:

Model Main Power(kw) Capacity(t/h) Feeding Power(KW) Conditioner Power(kw) Die Diameter(mm) Pellet size(mm)
LH-320 37 0.2-0.3 1.5 2.2 320 6,8,10,12
LH-350 55 0.5-0.7 1.5 3 350 6,8,10,12
LH-420 90 0.8-1.2 2.2 5.5 420 6,8,10,12
LH-480 90 1.0-1.3 2.2 5.5 480 6,8,10,12
LH-508 132 1.7-2.2 2.2 5.5 508 6,8,10,12
LH-558 160 2.0-2.5 2.2 5.5 572 6,8,10,12
LH-678 185 2.5-3.5 3 11 678 6,8,10,12
LH-768 250 4.0-5.5 4 18.5 768 6,8,10,12

Wood Pellet Machine 1

Introducing:

Ring die wood pellet mill is widely used in compacting of wood, straw, other biomass sources into pellet. Capacity ranges from 1T to 10T per hour. Our LH series pellet mill adopt SKF bearings from Sweden and NSK bearings from Japan, Siemens motors, high quality components make the pellet mill more efficient and durable.

downLoadImg (2)_副本

More Details Pictures of Wood Pellet Machine:

                         Main body with Siemens motor                                Breaking bridge type feeder

downLoadImg (3)_副本

                         Forged main shaft                                                            Germany Imports  FAG bearings

downLoadImg (4)_副本

Raw materials and final pellets:

The Raw material can be crops of corn stalk, wheat straw, rice straw, peanut shell, corn cob, cotton, soybean pole, chaff, weed,branches, leaves, sawdust, tree bark and other solid wastes.

complete wood pellet making line

Features:

1) Adopt high-precision gear drive advanced flexible coupling, for high productive efficiency.
2) Main driving adopt imported FAG bearing, and Siemens motor.
3) Frequency converter control feeder flow, full stainless steel cover and chute.
4) Full stainless steel lengthened conditioner; both paddle and shaft are made of stainless steel.
5) With CE certificate.
6) Available for testing before delivery.

Complete Wood Pellet Production Line:

Wood Pellet Making Line







Technical Data

Technical Data:

ModelMain Power(kw)Capacity(t/h)Feeding Power(KW)Conditioner Power(kw)Die Diameter(mm)Pellet size(mm)
LH-420900.8-1.22.25.54206,8,10,12
