Automatic Wood Feed Pellet Packaging Machine Grains Rice Sugar Packing Machine with Sealer

Range of Application

It is suitable for the quantitive packaging of granules in food, grain ,fodder, Sugar making nad chemical industry,etc.

Features

u  New controller with high precision can display the total weight, number of package, easy operation.

u  The adaptive software, having the function of automatic control parameters setting, automatic drop revising, over-weight warning and auto-diagnosis.

u  Wide packing range, it can match well with conveyor and sewing machine

u  Adopt imported sensor, pneumatic actuator, easy maintenance and non-pollution.

u  The main materials body is carbon steel, with painted plastic. And material contact part is stainless iron, corrosion resistance, long service life

u  Communication interface can be offered if need, realization of data communication with PC

Main Data:

Model Name	DB-1A	DB-5A	DB-25A	DB-50A	DB-100A
Packing Range	0.2-1kg	1-5kg	2.5-25kg	5-50kg	10-100kg
Packing Error	0.2%F.S	0.2%F.S	0.1 %F.S	0.1 %F.S	0.1 %F.S
Packing Speed	300-500 bags/h	300-500 bags/h	300-420 bags/h	≥300 bags/h	≥ 300 bags/h
Division Value	2g	5g	10g	20g	20g
Power	AC 220V 50Hz
Air Supply	0.4-0.8 MPa
Machine Dimension	1725x620x710 (mm)	1890x620x710 (mm)	2450x650x715 (mm)	2560x650x715 (mm)	2960x730x775 (mm)
Actuator	pneumatics
Accuracy Class	X(0.2)    X(0.1)

  Heat seal packing machine                            Sewing machine packing machine                    With heat sealer and sewing machine

                             Single scale packing machine                                                                     Double scales packing machine



Model Name	DB-1A	DB-5A	DB-25A	DB-50A	DB-100A
Packing Range	0.2-1kg	1-5kg	2.5-25kg	5-50kg	10-100kg
Packing Error	0.2%F.S	0.2%F.S	0.1 %F.S	0.1 %F.S	0.1 %F.S
Packing Speed	300-500 bags/h	300-500 bags/h	300-420 bags/h	≥300 bags/h	≥ 300 bags/h
Division Value	2g	5g	10g	20g	20g
Power	AC 220V 50Hz
Air Supply	0.4-0.8 MPa
Machine Dimension	1725x620x710        (mm)	1890x620x710        (mm)	2450x650x715        (mm)	2560x650x715        (mm)	2960x730x775        (mm)
Actuator	pneumatics
Accuracy Class	X(0.2)    X(0.1)
